Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
Type 5 - Vehicle Wiring Reference Chart
Page 18
Function Color Pin Polarity Location Color Pins
Dodge Caliber 2007-2012
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White/Pink 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay power Red N/A (+) Battery or TIPM on passenger fender. N/A N/A
Driver Door Trigger Violet/Dk. Blue 17 (-) Under driver dash. Black 43
Dodge Dakota 2007-2011
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White/Pink or White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Driver Door Trigger Violet or Violet/White 13 (-) Under driver dash above kick panel. Black 72
Dodge Durango 2007-2009
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White/Pink 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Orange/Dk.Blue 39 (+) Drivers kick panel fuse box. Gray 40
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Driver Door Trigger Violet 5 (-) Drivers door module in drivers door. Brown 20
Jeep Compass 2007-2016
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch Black 8
FT CAN Low White/Pink 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel harness to rear of vehicle. N/A N/A
Driver Door Trigger Violet/Dk. Blue 17 (-) Under drivers dash. Black 43
Jeep Patriot 2007-2016
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White/Pink 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel harness to rear of vehicle. N/A N/A
Driver Door Trigger Violet/Dk. Blue 17 (-) Under drivers dash. Black 43
Mitsubishi Raider 2007-2009
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay Power Re 2 (+) Connector above drivers kick panel. White 3
Driver Door Trigger Violet 13 (-) Under drivers dash above kick panel. Black 72
Wire Information Connector Information
