16
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Mustang 2013-2014
RX Yellow/Orange 4 Data (PATS) connector. Black 4 A
TX Violet/Gray 3 Data (PATS) connector. Black 4 A
12V Lt. Green/Violet or Blue/
Red
4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition Gray/Violet 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Keysense Blue/Gray 5 (+) Ignition switch. Black 7 B
Parking Lights Violet/White 6 (+) SJB (Smart Junction Box) in passenger kick
panel.
Gray 13 J
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB in passenger kick panel. Gray 26 I
Lock Blue/Green 17 (-) SJB in passenger kick panel. Gray 26 I
Unlock Yellow/Violet 4 (-) SJB in passenger kick panel. Gray 26 I
Trunk/Hatch Release Brown/Yellow (Coupe);
Brown/Yellow or Brown/
Violet (Convertible)
20 (-) SJB in passenger kick panel. Gray 26 I
Tach Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/
Orange, Brown, Green/
White, Gray/Brown or
Violet/Orange
1 (AC) Any fuel injector. Gray or Black 2 N/A
Ford Sport Trac 2008-2010
RX Yellow/Orange 4 Data (PATS) connector. Black 4 A
TX Violet/Gray 3 Data (PATS) connector. Black 4 A
12V Violet/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Keysense Blue/Gray 5 (+) Ignition switch. Black 7 B
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 17 Cut Fuse/SJB (Smart Junction Box) under
drivers dash.
Black 32 G
Lock Gray/Yellow 6 (-) Fuse/SJB under drivers dash. Black 32 G
Unlock Yellow/Violet 8 (-) Fuse/SJB under drivers dash. Black 32 G
Tach NOT Violet N/A (AC) Any fuel injector. N/A N/A N/A
