Page #52 background image
52
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Configuring the system
Important!
Once the DS4+ module is installed in the vehicle following the instructions in "Installation (wiring diagrams, fuse selection & vehicle
wiring reference charts)" on page 8, launch the DirectLink application on your mobile device, and select Configure DS4/
DS4+. Follow the on-screen instructions to configure the system.
Note: Your system can also be configured using XKLoader2 on www.directechs.com.
Vehicles equipped with a manual transmission
Additional connections may be required if these functions are not supported by the firmware.
Connection Description
(-) E-Brake Status Input
(Black/White, pin 17)
Must be connected to a working emergency brake in the vehicle. Although most vehicles have simple
(-) trigger emergency brake circuits note some vehicles do not and may require unique integration
methodologies.
(-) Door Trigger Input
(Green, pin 20) OR
(+) Door Input (Violet, pin
13)
Must be connected to a working door trigger in the vehicle, which monitors all doors. The unit must monitor
the door pins to allow the Ready Mode process to be enabled.
Note: Some vehicles may require unique integration methodologies for this circuit. For more information, refer
to www.directechs.com.
(AC) Tachometer Input
(Violet/White, pin 22)
Must be connected to a working tachometer signal in the vehicle (fuel injector, ignition coil, true tach, etc.)
and learned successfully to the DS4+.
RF Systems
An RF System consists of one or multiple remotes, a Control Center (antenna), and an antenna cable – various combinations exist.
An RF System allows the vehicle owner to control the system with enhanced range. Two-way models are available. Please follow
the instructions included with the kit for appropriate installation and programming information.
8504D Combo Sensor
The 8504D Combo Sensor must be paired to the device before it can be used. To enter pairing, turn the vehicle ignition to the
ON position, then press and hold the programming button on the Control Center (antenna) until the LED starts flashing. Once
pairing mode has been entered, your Combo Sensor is ready to use.
Your Combo Sensor is preset for the majority of applications, however it can be adjusted using the DirectLink application, as well
as a compatible LED or LCD remote. Please refer to the instructions included with your sensor for more information on how to make
adjustments.
