lPage 73
DishPro Wiring Diagrams
TWO DISHES, THREE SINGLE-OUTPUT DISHPRO LNBFS, THREE
CABLES, ONE DP34 SWITCH, MULTIPLE DISHPRO
RECEIVERS (ALL DISHPRO)
This diagram leaves out grounding to be clear. Make sure you
ground the system per the National Electrical Code (NEC)
and all local electrical codes. Please see Ground the System
on page page 90 for more information
When you set up your system following this diagram and run Check
Switch the Installation Summary screen should look similar to the
one shown below.
