Configuration Parameters
Parameter Description Min Max Meas. Resolution
CF01 Unit model:
0= Chiller air / air
1= Chiller air / air with heat pump
2= Chiller air / water
3= Chiller air / water with heat pump
4= Chiller water / water
5= Chiller water / water with heat pump
0 5
CF02 Motocondensing unit
0= No
1= Yes
0 1
CF03 Regulation probe
0= Pb1 regulation
1= Pb2 regulation
0 1
CF04 Pb1 configuration
0= Probe not enabled
1= NTC temperature of evaporator inlet
2= Digital input for temperature regulation demand
3= Digital input cooling demand
0 3
CF05 Pb2 configuration
0= Probe not enabled
1= NTC temperature of evaporator outlet
2= Digital Input for antifreeze alarm
3= Digital input for heating demand
0 3
CF06 Pb3 configuration
0= Probe not enabled
1= NTC temperature condensing control
2= 4..20mA for condensing pressure
3= 4..20ma for Dynamic Set point
4= NTC temperature for anti freeze alarm (water/water)
0 4
CF07 Pb4 configuration
0= Probe not enabled
1= NTC condensing control
2= Multifunction digital input
3= External air temperature
4= NTC temperature for anti freeze alarm (water/water)
5= NTC temperature for combined defrost
6= NTC temperature for logging
0 6
CF08 ID1 configuration
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Supply air fan thermal protection
3= Remote On/off
4= Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
0 9
