IC100C Series PRELIMINARY
1592015000 Manual IC100C Series 28/05/03 Page 29 di 38
CF09 ID2
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Supply air fan thermal protection
3= Remote On/off
4= Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
0 9
CF10 ID5 configuration
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Supply air fan thermal protection
3= Remote On/off
4= Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
0 9
CF11 Pb4 configuration in digital input mode
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Supply air fan thermal protection
3= Remote On/off
4= Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
0 9
CF12 ID1 input polarity
0= active for closed contact
1= active for open contact
0 1
CF13 ID2 input polarity
0= active for closed contact
1= active for open contact
0 1
CF14 ID3 input polarity
0= active for closed contact
1= active for open contact
0 1
CF15 ID4 input polarity
0= active for closed contact
1= active for open contact
0 1
CF16 ID5 input polarity
0= active for closed contact
1= active for open contact
0 1
CF17 Pb1 input polarity
0= active for closed contact
1= active for open contact
0 1
CF18 Pb2 input polarity
0= active for closed contact
1= active for open contact
0 1
