IC100C Series PRELIMINARY
1592015000 Manual IC100C Series 28/05/03 Page 35 di 38
DF03 Temperature / pressure Setpoint for starting the defrost
cycle
-40.0
- 40
0.0
0
110
230
30
435
°C
°F
Bar
Psi
Decimal
integer
Decimal
integer
DF04 Temperature / pressure Setpoint for stopping the defrost
cycle
-40.0
- 40
0.0
0
110
230
30
435
°C
°F
Bar
Psi
Decimal
integer
Decimal
integer
DF05 Minimum delay time before starting a forced defrost cycle 0 250 Sec
DF06 Minimum defrost duration 0 250 Sec
DF07 Maximum defrost duration 0 250 Min
DF08 Compressor Off time before starting a defrost cycle 0 250 Sec
DF09 Compressor Off time after a defrost cycle 0 250 Sec
DF10 Interval time between defrost cycles 0 99 MIN
DF11 Temperature setpoint to start a combined defrost cycle after
the DF10 counting time
-40
-40
110
230
°C
°F
Decimal
integer
DF12 Temperature Setpoint to stop a combined defrost -40
-40
110
230
°C
°F
Decimal
integer
DF13 Forced activation of the 2
nd
compressor in defrost
0= Not enabled
1= Enabled
0 1
DF14 Forced fan activation during defrost and draining times
0= Not enabled
1= Enabled only for defrost
2= Enabled for defrost and draining time (dF09)
0 2
DF15 Temperature/Pressure Setpoint to start a forced condensing
fan control in defrost cycle
-40.0
- 40
0.0
0
110
230
30
435
°C
°F
Bar
Psi
Decimal
integer
Decimal
integer
DF16 Low alarm control during defrost
0= Not enabled
1= Enabled
0 1
DF17 Low alarm delay time after changing the status of the 4-
ways valve
0 250 Sec
DF18 4-ways reversing valve
0= ON in cooling
1= ON in heating
0 1
DF19 Temperature/pressure Setpoint to start a forced defrost
cycle
-40.0
- 40
0.0
0
110
230
30
435
°C
°F
bar
psi
Decimal
integer
Decimal
integer
DF20 Forced defrost cycle differential 0
0
25.0
45
°C
°F
Decimal
integer
Pr2 Password 0 999
Alarm Parameter
Parameter Description Min Max Meas. Resolution
AL01 Low pressure alarm delay time 0 250 Sec
AL02 Maximum low pressure alarm events in 1 hour 0 16
AL03 Low pressure alarm with off compressor
0= Not enabled when compressor Off
1= Enabled when compressor Off
0 1
AL04 “Water flow/Supply fan thermal protection” alarm delay after
“water pump / supply air fan” starting.
0 250 Sec
