dixell ichill IC100C series User Manual

IC100C Series PRELIMINARY
1592015000 Manual IC100C Series 28/05/03 Page 34 di 38
Ar07 Anti-Freeze alarm delay after starting in Heat Pump 0 250 Sec
Ar08 Anti-Freeze Setpoint of the electrical heater in Chiller mode -40
-40
110
230
°C
°F
Decimal
integer
Ar09 Anti-Freeze Setpoint of the electrical heater in Heat Pump
mode
-40
-40
110
230
°C
°F
Decimal
integer
Ar10 Anti-Freeze Setpoint of external electrical heater
(water/water units)
-40
-40
110
230
°C
°F
Decimal
integer
Ar11 Anti-Freeze Differential in Chiller 0
0
25.0
45
°C
°F
Decimal
integer
Ar12 Anti-Freeze Differential in Heat Pump 0
0
25.0
45
°C
°F
Decimal
integer
Ar13 Anti-freeze electrical heater regulation
0= enabled during regulation control
1= enabled active during regulation an defrost
0 1
Ar14 Anti-freeze electrical heater regulation in Chiller mode
0= OFF in chiller
1= ON in chiller
0 1
Ar15 Anti-freeze electrical heater regulation in H.P. mode
0= OFF in Heat Pump
1= ON in Heat Pump
0 1
Ar16 Anti-freeze control probe in Chiller mode
0= Pb1
1= Pb2
0 1
Ar17 Anti-freeze control probe in Heat Pump mode
0= Pb1
1= Pb2
0 1
Ar18 “Water pump”/ “Anti-freeze electrical heater” control with unit
in OFF or Stand-by
0= Regulation not enabled
1= Regulation enabled
0 1
Ar19 “Water pump”/ “Anti-freeze electrical heater” control for
faulty probe
0= output OFF for faulty probe
1= output ON for faulty probe
0 1
Function Boiler
Parameter Description Min Max Meas. Resolution
Ar20 Boiler function
0= Integration control
1= Heating control
0 1
Ar21 External air Setpoint for Boiler heater activation -40.0
-40
110
230
°C
°F
Decimal
integer
Ar22 Boiler function differential 0
0
25.0
45
°C
°F
Decimal
integer
Pr2 Password 0 999
Defrost Parameters
Parameter Description Min Max Meas. Resolution
DF01 Defrost control
0= No
1= Yes
0 1
DF02 Defrost type
0= Temperature / pressure
1= Time
2= External contact
0 2
