dji FLYCART 30 Flight Manual

DJI FlyCart 30 User Manual
90
©
2024 DJI All Rights Reserved.
RTK/GNSS Operating
Frequency
RTK: GPS L1/L2, Galileo F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b,
QZSS L1/L2
GNSS: GPS L1, BeiDou B1I, Galileo F1, Galieo E1, QZSS L1
Max Pitch Angle 30°
Max Ascent Speed 5 m/s
The data was measured in an experimental environment with zero
altitude and no wind, with 30 kg load weight, for reference only.
Max Descent Speed 3 m/s (vertical)
5 m/s (tilted descent)
The data was measured in an experimental environment with zero
altitude and no wind, with 30 kg load weight, for reference only.
Max Horizontal Speed 20 m/s
The data was measured in an experimental environment with zero
altitude and no wind, with 30 kg load weight, for reference only.
Max Takeo Altitude 6000 m (empty weight)
Max Wind Speed
Resistance
12 m/s
The data was measured in an experimental environment with zero
altitude, with 30 kg load weight, for reference only.
Power System
Stator Size 100 x 33 mm
Motor KV Value 48 rpm/V
Max Motor Power 4000 W/rotor
Propellers Material Carbon ber composite
Propellers Diameter 54 inch
Propellers Type Foldable double-blade propeller
Main-rotor Diameter 1375 mm
Rotor Quantity 8
LED Light
Eective Illumination
Distance
10 m
Illumination Mode 60 Hz, automatically switch on according to ambient light
DJI O3 Image Transmission
Model Pigeon (with DDR)-2T4R
Signal Eective Distance 20 km (FCC)
8 km (CE/SRRC/MIC)
Measured in an unobstructed environment with no interference
Operating Frequency 2.4000-2.4835 GHz
5.725-5.850 GHz
Some countries or regions do not support the 5.8 GHz frequency
band. Please refer to local ight laws and regulations for details.

dji FLYCART 30 Specifications

General

Max Payload	30 kg
Max Flight Speed	20 m/s
Max Wind Resistance	12 m/s
Intelligent Battery	Yes
Aircraft Type	Multi-rotor
Hovering Accuracy	Vertical: ±0.1 m
Operating Temperature Range	-20°C to 45°C
