dji FLYCART 30 Flight Manual

DJI FlyCart 30 User Manual
©
2024 DJI All Rights Reserved.
91
EIRP 2.4000 GHz-2.4835 GHz:
<33 dBm (FCC)
<20 dBm (CE/SRRC/MIC)
5.725 GHz - 5.850 GHz:
<33 dBm (FCC)
<30 dBm (SRRC)
<14 dBm (CE)
Data Security AES-256
ADS-B Supported
Active Phased Forward and Backward Array Radar
Model Number RD241608RF (forward)
RD241608RB (backward)
Altitude Detection Fixed altitude range: 1.5-200 m
Rear Obstacle Avoidance Sensible distance (rear): 1.5-50 m
FOV:
Forward: 360° horizontal, ±45° vertical, ±45°upward
Backward: ±45° horizontal, 360° vertical
Operating conditions: Available during takeo, landing, and
ascending when an obstacle is more than 1.5 m away from the
aircraft
Safe distance: 3.5 m (distance between the propeller tip and obstacle
when the aircraft is hovering after braking)
Sensing direction: multi-direction
Binocular Vision System
FOV Horizontal: 90; Vertical: 106°
Work Environment
Requirements
Non-reective, discernible surfaces with diuse reectivity of >20%,
such as concrete or tarmac. Adequate lighting of lux >15 Surface
with a clear pattern
FPV Camera
Resolution 1920 x 1440
DFOV 149°
Frame Rate 30fps
Type Full HD FPV Single Axis Gimbal Camera
Fill Light Supported
Cargo Case
Dimensions 754 x 472 x 385 mm (L x W x H)
Inner Space 573 x 416 x 306 mm (L x W x H)
Material EPP plus aluminum alloy frame
Weighing Feature Supported
Weight Approx. 3 kg
Load Capacity 0-40 kg

dji FLYCART 30 Specifications

General

Max Payload	30 kg
Max Flight Speed	20 m/s
Max Wind Resistance	12 m/s
Intelligent Battery	Yes
Aircraft Type	Multi-rotor
Hovering Accuracy	Vertical: ±0.1 m
Operating Temperature Range	-20°C to 45°C
