dji MAVIC 3T User Manual

47
©
2022 DJI All Rights Reserved.
4:53
5
DJI Pilot 2
Firefox
Guide
Setting
Gallery
Files
Remote Controller
The DJI RC Pro Enterprise remote controller features O3 Enterprise. The latest version of
DJI's signature OcuSync image transmission technology works at both 2.4 and 5.8 GHz, is
capable of selecting the best transmission channel automatically, and can transmit a live HD
view from the camera of the aircraft at a distance of up to 15 km. The built-in 5.5-in high-
brightness 1000 cd/m
2
screen boasts a resolution of 1920×1080 pixels, while the remote
controller comes with a wide range of aircraft and gimbal controls and customizable
buttons. Users can connect to the internet via Wi-Fi, and the Android 10 operating system
comes with a variety of functions such as Bluetooth and GNSS (GPS+GLONASS+Galileo).
With the built-in microphone and speaker, the remote controller supports H.264 4K/120fps
and H.265 4K/120fps video (the actual display effect depends on the resolution and frame
rate of the screen), which also supports video output via the Mini HDMI port. The internal
storage of the remote controller is 64 GB and supports the use of microSD cards to store
photos and videos.
The 5000mAh 36Wh battery provides the remote controller a maximum operating time of 3
hours.
Remote Controller System Interface
Homepage
1
2 3 4 5 6 7
8 9

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
