dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
44
©
2022 DJI All Rights Reserved.
Storing Photos and Videos
A microSD card is in the microSD card slot when shipped. The aircraft supports microSD
cards with a maximum capacity of up to 512 GB. To ensure that the camera can quickly
read and write data for HD video recording, use a microSD card with UHS Speed Class 3 or
above and a write speed greater than 30 MB/s. Refer to the Recommended microSD Cards
in specifications.
• DO NOT remove the microSD card from the aircraft when recording. Otherwise, the
microSD card may be damaged.
• To ensure the stability of the camera system, single video recordings are limited to 30
minutes.
• Check camera settings before use to ensure they are configured correctly.
• Before shooting important photos or videos, shoot a few images to test whether the
camera is operating correctly.
• Photos and videos cannot be transmitted or copied from the camera if the aircraft is
powered off.
• Make sure to power off the aircraft correctly. Otherwise, the camera parameters will
not be saved, and any recorded videos may be affected. DJI is not responsible for any
loss caused by an image or video recorded in a way that is not machine-readable.
PSDK Port
DJI Mavic 3E/3T features a PSDK port for mounting additional compatible DJI modular
accessories that are listed below:
Speaker: used for long-range, real-time broadcasting or audio playback.
RTK module: tracks the dual-frequency multi-mode signals of visible satellites in complex
environments, provides higher accuracy and more reliable data for positioning, and
improves the anti-interference ability in strong magnetic environments, which ensures
reliable operation and flight. When used with a D-RTK 2 High Precision GNSS Mobile Station
or a custom Network RTK, more accurate positioning data can be obtained.
Speaker RTK Module

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
