dji MAVIC 3T User Manual

57
©
2022 DJI All Rights Reserved.
DJI Pilot 2 App
The DJI Pilot 2 app is specifically developed for enterprise users. Manual flight integrates a
variety of professional features that make flying simple and intuitive. Flight task supports
flight planning and autonomous operation of the aircraft, making your workflow much
simpler and more efficient.
Homepage
1. Profile
Tap to view flight records, download offline maps, manage GEO Zone unlocking, read
help documentation, select a language, and view app information.
2. Data and Privacy
Tap to manage network security modes, set security codes, manage app cache, and
clear DJI device logs.
3. GEO Zone Map
Tap to view the GEO Zone map, check offline whether the current operating area is in a
restricted zone or authorization zone, and the current flyable altitude.
1 2 3 4
5
6
7
8
9
10

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
