dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
55
©
2022 DJI All Rights Reserved.
Optimal Transmission Zone
The signal between the aircraft and the remote controller is most reliable when the
antennas are positioned in relation to the aircraft, as illustrated below.
The optimal transmission range is where the antennas face the aircraft, with the angle
between the antennas and the back of the remote controller being 180° or 270°.
Linking the Remote Controller
The remote controller is already linked to the aircraft when purchased together as a combo.
Otherwise, follow the steps below to link the remote controller and the aircraft after
activation.
Method 1: Using Button Combinations
1. Power on the aircraft and the remote controller.
2. Press the C1, C2, and Record buttons simultaneously until the status LED blinks blue and
the remote controller beeps.
3. Press and hold the power button of the aircraft for more than four seconds. The aircraft
beeps twice after a short beep, and its battery level LEDs blink in sequence to indicate
it is ready to link. The remote controller will beep twice, and its status LED will turn solid
green to indicate linking is successful.
Combination Operation Function
Back Button + Left Dial Adjust Brightness
Back Button + Right Dial Adjust Volume
Back Button + Record Button Record Screen
Back Button + Shutter Button Screenshot
Back Button + 5D Button Toggle up - Home; Toggle down - Shortcut settings; Toggle
left - Recently opened apps

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
