Flight Recorder
Flight data, including flight telemetry, aircraft status information, and other parameters, are
automatically saved to the internal data recorder of the aircraft. The data can be accessed
using DJI Assistant 2 (Enterprise Series).
Propellers
There are two types of DJI Mavic 3E/3T Quick-Release Propellers designed to spin in
different directions. Marks are used to indicate which propellers should be attached to
which motors. Make sure to match the propeller and motor following the instructions.
Attaching the Propellers
Attach the propellers with marks to the motors with marks and the unmarked propellers
to the motors without marks. Hold the motor, press the propeller down, and rotate in the
direction marked on the propeller until it pops up and locks in place.
B A
A B
1
2
Detaching the Propellers
Hold the motor, press the propeller down, and rotate in the opposite direction to the one
marked on the propeller until it pops out.
• The propeller blades are sharp. Handle with care.
• Only use official DJI propellers. DO NOT mix propeller types.
• Propellers are consumable components. Purchase additional propellers if necessary.
• Make sure that the propellers and motors are installed securely before each flight.
• Make sure that all propellers are in good condition before each flight. DO NOT use
aged, chipped, or broken propellers.
• To avoid injury, stay away from rotating propellers or motors.
• To avoid damaging the propellers, place the aircraft in the direction shown in
the carrying case during transportation or storage. DO NOT squeeze or bend the
propellers. If propellers are damaged, the flight performance is affected.
• Make sure the motors are mounted securely and rotating smoothly. Land the aircraft
immediately if a motor is stuck and unable to rotate freely.

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
