dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
50
©
2022 DJI All Rights Reserved.
Remote Controller LEDs and Alerts
Remote Controller LEDs
Status LED
Blinking Pattern Descriptions
Solid red Disconnected from the aircraft
Blinks red The temperature of the remote controller is too high, or the battery
level of the aircraft is low
Solid green Connected with the aircraft
Blinks blue The remote controller is linking to an aircraft
Solid yellow Firmware update failed
Blinks yellow The battery level of the remote controller is low
Blinks cyan Control sticks not centered
Battery Level LEDs
Blinking Pattern Battery Level
76%-100%
51%-75%
26%-50%
1%-25%
Remote Controller Alert
The remote controller vibrates or beeps twice to indicate an error or warning. Pay attention
to the prompts that appear on the touchscreen or in DJI Pilot 2. Slide down from the top
and select Mute to disable alerts.

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
