dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
43
©
2022 DJI All Rights Reserved.
Camera
Camera Profile
Both DJI Mavic 3E and DJI Mavic 3T integrate a tele camera and a wide camera, which
enable users to quickly switch to a highly magnified zoom view for detailed observation
after recognizing a target in the wide-angle camera view. Mavic 3T is also equipped with a
long-wave infrared thermal imaging camera, which can shoot thermal images.
Thermal Camera
Wide Camera
Wide Camera
Tele Camera
Tele Camera
Mavic 3T Mavic 3E
Mavic 3E
Mavic 3E's wide-angle 4/3 CMOS, 20MP sensor has a mechanical shutter to prevent motion
blur and supports rapid 0.7-second interval shooting. Large 3.3 μm pixels that, together
with Smart Low-Light Photo, offer significantly improved performance in dim conditions.
The tele camera boasts a 1/2-in CMOS sensor, capable of shooting 12MP photos with an
aperture of f/4.4 and shooting at 3 m to infinity, supporting up to 56× Max Hybrid Zoom.
Mavic 3T
Mavic 3T’s wide camera boasts a 1/2-in CMOS sensor, capable of shooting 48MP photos
with an aperture of f/2.8 and shooting at 1 m to infinity.
The tele camera boasts a 1/2-in CMOS sensor, capable of shooting 12MP photos with an
aperture of f/4.4 and shooting at 3 m to infinity, supporting up to 56× Max Hybrid Zoom.
The thermal camera has 640×512 resolution and, together with the tele camera, supports
28× continuous side-by-side zoom for easy comparisons.
• DO NOT expose the thermal camera lenses to strong sources of energy such as the
sun, lava, or a laser beam. Otherwise, the camera sensor may be burned, leading to
permanent damage.
• Make sure the temperature and humidity are suitable for the camera during use and
storage.
• Use a lens cleanser to clean the lens to avoid damage or poor image quality.
• DO NOT block any ventilation holes on the camera as the heat generated may damage
the device and injure the user.

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
