dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
14
©
2022 DJI All Rights Reserved.
scale power transmission stations or mobile base stations, and broadcasting towers.
The aircraft may behave abnormally or lose control when flying in areas with too much
interference. Return to the Home Point and land the aircraft if prompted to do so in DJI
Pilot 2.
Vision Systems and Infrared Sensing System
DJI Mavic 3E/3T is equipped with both an Infrared Sensing System and Horizontal
Omnidirectional (Forward, Backward, Lateral), Upward, and Downward Vision Systems.
The Upward and Downward Vision Systems consist of two cameras each, and the
Forward, Backward, and Lateral Vision Systems consist of four cameras in total.
The Infrared Sensing System consists of two 3D infrared modules. The Downward
Vision System and Infrared Sensing System help the aircraft maintain its current
position, hover more precisely, and fly indoors or in other environments where GNSS is
unavailable.
In addition, the Auxiliary Bottom Light located on the underside of the aircraft improves
visibility for the Downward Vision System in weak light conditions.
Detection Range
Forward Vision System
Precision Measurement Range: 0.5-20 m; FOV: 90° (horizontal), 103° (vertical)
Backward Vision System
Precision Measurement Range: 0.5-16 m; FOV: 90° (horizontal), 103° (vertical)
Lateral Vision System
Precision Measurement Range: 0.5-25 m; FOV: 90° (horizontal), 85° (vertical)
Upward Vision System
Precision Measurement Range: 0.2-10 m; FOV: 100° (front and back), 90° (left and right)
Downward Vision System
Precision Measurement Range: 0.3-18 m; FOV: 130° (front and back), 160° (left and right).
The Downward Vision System works best when the aircraft is at an altitude of 0.5 to 30 m.
Horizontal Omnidirectional Vision System
Infrared
Sensing System
Auxiliary Bottom Light
Downward Vision System
Upward Vision System
Horizontal Omnidirectional
Vision System

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
