dji P4 MULTISPECTRAL User Manual

P4 Multispectral User Manual
8
©
2019 DJI All Rights Reserved.
Preparing the Remote Controller
1. Tilt the mobile device holder or the display device on the remote controller to the desired
position, then adjust the antennas so they are facing outward.
2. Connecting your mobile device
1
Press the button on the top right side of the mobile device holder to release the clamp, then
adjust the clamp to t the size of your mobile device.
2
Secure your mobile device in the clamp by pressing down.
3
Plug one end of the cable into the mobile device, and the other end into the USB port on
the back of the remote controller.
2
1
3
Activating the Aircraft
When using your P4 Multispectral for the rst time, activate it using DJI GS Pro. Ensure that your
iPad has access to the internet.

dji P4 MULTISPECTRAL Specifications

General

Type	Quadcopter
Product color	White
Suitable for outdoor use	Yes
Maximum speed	6 m/s
Frequency band	2.4 - 2.48 GHz
Number of rotors	4 rotors
Integrated sensors	Infrared (IR) sensor
Maximum flight time	27 min
Maximum descent speed	3 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	1.487 kg
Megapixel	2.08 MP
Image formats supported	JPEG, TIFF
Field of view (FOV) angle	62.7 °
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Battery voltage	15.2 V
Battery capacity	5870 mAh
Manual languages	English
Memory card included	MicroSD
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Battery weight	468 g
Takeoff weight (max)	1487 g
