iPad Ground
Station
iPad Ground
Station
+ -
3S-6S
Battery
3S-6S
Battery
Air End
Ground End
Figure 1-10
Connect the Air End of 2.4G Bluetooth Datalink to a spared CAN-Bus port of iOSD if an iOSD is used.
（6） Using the PC Ground Station
Air End
Ground End
PC Ground
Station
Figure 1-11
