Spark User Manual
1 m
Exiting Coordinate Mode
Use the following methods to exit Coordinate Mode:
1. Tap the icon on the screen.
2. Pull back the pitch stick on the remote controller for three seconds or more.
3. Press the Flight Pause button on the remote controller.
4. Drag the blue circle left and right.
Direction Mode
Keep ying in the direction you tap on the screen.
Using Direction Mode
Ensure the Intelligent Flight Battery is fully charged and the aircraft is in P Mode. Follow the steps below to
use Direction Mode:
1. Take off and ensure the aircraft is ying at least 3 ft (1 m) above the ground.
S 1.1D 9.6
H 9.6
61%
P-GPS
12
09:29
2.4G
In-Flight（GPS）
1080P/30
2. Launch DJI GO 4 and tap . Select TapFly, switch to Direction Mode, then follow the prompts.
61%
TapFly
12
09:29
2.4G
In-Flight（GPS）
1080P/30
3. Tap once on the target and wait for the “GO” icon to appear. Tap the “GO” icon to confirm the
selection and the aircraft will y in that direction automatically.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
