Spark
User Manual
Adjusting Position
1. Move your palm up or down slowly to control
the aircraft’s altitude while maintaining a
constant distance between your palm and the
aircraft.
——
Solid green
2. Keep your palm at a constant distance from
your body (as shown), then move your arm left
or right to control the aircraft’s orientation.
3. Keep your palm at a constant distance from
your body, move forward or backward to y
forward or backward.
Follow
1. Stand in front of the aircraft then raise one
of your arms and quickly wave your hand at
the camera. Position your palm about 0.7 m
in front of the aircraft's nose for about two
seconds.
×2
Blinks green twice
2. The front LEDs will blink green twice if
the gesture is recognized successfully.
The aircraft will ascend and y backward,
then hover in place 3 m from where you’re
standing, 2.3 m above ground. Do not move
your body until the aircraft hovers in place.
3. The front LEDs will glow solid green and the
aircraft will start tracking automatically.
——
Solid green
4. If the wave gesture fails or the aircraft loses
track of you, you can activate Follow by raising
both arms above your head in a Y shape, then
holding for two seconds.
Taking Seles
1. Make a frame with your hands within 23 ft (7 m)
of the aircraft while facing toward the camera
and it will begin taking a sele.
Blinks red slowly
2. Sele gesture has been recognized
successfully if the Front LEDs blink red
slowly. Wait for the sele count down for three
seconds. The Front LEDs will blink red quickly,
indicating the camera is about to take a sele.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
