dji SPARK User Manual

©
2017 DJI All Rights Reserved.
25
Spark User Manual
Beckon
1. Raise your arms above your head in a Y
shape for two seconds after the aircraft starts
tracking.
——
Solid red
2. When Beckon is successfully activated, the
aircraft will y toward you and hover in place
1.5 m above ground and 1.2 m away from
you.
3. The front LEDs will turn solid red.
PalmLand
Face toward to the camera and place your palm
approximately 0.5 m underneath the aircraft at a
distance of no further than 1.5 m away from you.
The aircraft will slowly descend and land on your
palm.
——
Solid red
It is highly recommended to install the Spark Propeller Guards before using Gesture Mode to
ensure safety.
Gesture Control needs to be enabled in DJI GO 4 by tapping .
Note that the resolution of photos is 1440×1080 in Gesture mode.
In PalmLaunch, the Aircraft Status Indicators will blink normally and will not display remote
signal loss, even without a mobile device or remote controller connected.
Use Gesture Mode in open areas.
Gesture Mode can only be used to take photos.
Enabling GPS on your mobile device will allow the aircraft to follow more accurately in Gesture
Mode.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
