dji ZENMUSE L1 User Manual

ZENMUSE L1
User Manual
10
©
2021
DJI All Rights Reserved.
17. Use one nger to drag the point cloud model and use two ngers to rotate or zoom in or out on the
point cloud model.
18. Tap to view the point cloud model beneath the aircraft.
19. Tap and the point cloud model will recenter and zoom in or out to display the whole model.
20. Tap to view the point cloud model from the top, north, east, south, or west.
NW 330°
500M 500M
T
N
E
S
W
Preview
17 18 19
20
15. Model Preview Button
Refer to the Point Cloud Model Preview section for more information.
16. Pause Button
Tap to pause point cloud recording and tap again to resume.
Point Cloud Model Preview
Tap to view the current point cloud model from dierent perspectives.

dji ZENMUSE L1 Specifications

General

Product type	Camera module
Compatibility	Matrice 300 RTK
Product color	Black
Brand compatibility	DJI
Operating temperature (T-T)	-20 - 50 °C
Megapixel	20 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Camera shutter speed	1/8000 - 8 s
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Image formats supported	JPEG
Video formats supported	H.264, MOV, MP4
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	95 °

Weight and Dimensions

Depth	169 mm
Width	110 mm
Height	152 mm
Weight	930 g
