9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 11
PAIR THE KEYPAD
You can program up to 7 wireless keypads in a panel with XR Series Version 191 (3/8/19) or
higher and XT Series Version (11/15/19) or higher.
9000 Series wireless keypads can be programmed into the control panel by using the
wireless keypad pairing operation or by entering the serial number in Device Setup.
The keypad logo is red when it is not paired to a panel. The keypad logo turns green when
it is paired to a panel. If the light is not on, the keypad is not receiving DC power. For more
information, refer to Table 3.
Note: If you’re programming the keypad as a device type manually, skip this section
and go to Device Setup.
During pairing, unaddressed keypads are automatically assigned to the first open device
address based on the order in which they are detected.
