Backlit Logo
The backlit logo indicates the armed status of the panel and the power and battery status
of the keypad.
COLOR AND ACTIVITY ARMED STATUS DC POWER STATUS BATTERY STATUS PAIRED
Green Steady Disarmed OK OK Yes
Green Blinking Disarmed OK Fault Yes
Red Steady Armed OK OK No
Red Blinking Armed Fault OK No
Red/Green Alternating Armed OK Fault Unknown
No Light Unknown Fault Unknown Unknown
Table 3: Logo Color and Behavior
