Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide 32
Replace the Battery
DMP recommends replacing the battery every 3years under normal use. Refer to Figure 9
and Figure 10 when replacing the battery.
Remove the Keypad PCB
1. Disconnect the power supply.
2. Loosen the top PCB snaps.
3. Lean the keypad backwards and lift out from the bottom PCB snaps.
Battery Replacement
1. Disconnect the battery lead connector from the keypad battery header.
2. Remove the standby battery from the PCB.
3. Observe polarity and connect the battery connector to the keypad battery header.
4. Using double-sided tape, place the new battery on the keypad PCB.
5. Properly dispose of the used battery.
Caution: Risk of fire, explosion, and burns. Do not disassemble, heat above
212°F (100°C), or incinerate.
Install the Keypad PCB
1. Ensure the keyboard is in place, then insert the PCB into the bottom snaps.
2. Line up the alignment post with the hole in the PCB.
3. Press the PCB into the top snaps to secure in place.
4. Place the keypad cover back onto the base and snap into place.
