Device Setup
Device Setup
Advance to Device Setup, then press a select area to enter the setup menu.
Device Number
Set the keypad address.
Panel Models Available Device Numbers
(Keypad Bus)
Available Device Number Range
(Network Connection including Wi-Fi)
XR550 1-16 2-16
XR150 1-8 2-8
XT30/XT50 1-8 2-8
XTLplus 0 2-8
XTLtouch 0 2-8
Refer to Network Options in the Program the Keypad section for the available number
of network keypads per panel model.
Device Name
Enter a name for the device.
Device Type (XR Only)
Select the Keypad device type.
Communication Type
XR Series Panels
For use as a standard keypad, select Keypad.
For use as a Wi-Fi keypad, select NET. To finish connecting the keypad to the panel via
Wi-Fi network, refer to Network Options in the Options menu.
XT/XTL Series Panels
For use as a standard keypad, select NO.
For use as a Wi-Fi keypad, select YES. To finish connecting the keypad to the panel via
Wi-Fi network, refer to Network Options in the Options menu.
DEVICE SETUP
DEVICE SETUP
DEVICE NO: -
DEVICE SETUP
*UNUSED*
DEVICE SETUP
TYPE: KEYPAD
DEVICE SETUP
COMM TYPE: KEYPAD
DEVICE SETUP
COMM TYPE: NET
NETWORK? NO YES
NETWORK? NO YES
