DoAll C-4100NC - Machine Start-Up

10
8. If the hydraulic or band drive motor overloads open,
the machine will shut down.
Machine Start-Up
Always use extreme care when handling
saw bands. DO NOT attempt to remove the
saw band cap while the band drive motor is
running.
1. To remove the protective Saw Cap (if necessary) from
the shipped-in-place saw band, turn the hydraulic
system on, if not already running. Then: (a) Move
the Saw Head Control selector joystick to "UP" and
raise the saw head to its maximum height; (c) If the
saw head does NOT raise, make sure the Operation
selector is in "MANUAL" mode; (d) Now move the
Saw Head Control selector joystick to "UP" and
raise the saw head to its maximum heigh.
2. Open both bandwheel doors and nd the ends of
the Saw Cap. Pull the cap off of the saw band. If
the cap is pinched onto the bandwheel, relax the
band tension by turning the Band Tension selector
switch to "OFF". The cap now should come off.
After removal, check to be sure that the saw
band rides properly on the bandwheels (the
back of the saw band must be up against the
wheelange).
3. After removal of the Saw Cap, turn the Band Tension
selector switch to "ON" to apply the correct band
tension.
The band drive motor will not start unless: (a)
Both bandwheel doors are closed; (b) The saw
band has been tensioned; (c) Hydraulics are
running.
PREPARATION FOR USE (Continued....)
