45
BAND TWIST INDICATOR (Continued....)
7. Sensitivity control allows the operator to set the
full scale of the display. "1" is the least sensitive
to twist and "10" is the most sensitive. The actual
values depend on the calibration of the device.
8. Man - Auto. This selector permits the operator to
select "MANUAL" operation (machine operation
is not interrupted by the band twist monitor), or
"AUTOMATIC" (the saw band is stopped when the
red LED's are lighted).
9. Reset. Push the button to turn off the ashing
indicators, etc.
BAND LUBRICATOR
1. See the instructions sent with the unit for information
on operation and adjustments.
WORKLIGHT
1. The worklight illuminates the cutting area and areas
nearby and is controlled by an "ON/OFF" switch on
the lamp.
5 FOOT INDEX OPTION
1. This factory installed option allows single indexes
of up to 60 inches (1524.0 mm) in length instead
of the standard 24 inches (609.6 mm). All other
operations and data remain the same.
LASER LINE OPTION
To avoid eye damage, DO NOT stare into the
laser beam.
1. A laser devise is used to emit a line on the material
to be cut. This line shows the approximate spot
where the cut will take place.
2. The devise is controlled by a selector switch with
"ON" and "OFF" settings and is located on or near
the electrical pushbutton panel. Turn the laser "OFF"
when not in use.
3. The laser is adjustable to position the laser beam
where desirable.
4. When the laser is turned on, a warm-up period of
3 to 5 seconds take place before a line appears. If
the line is difcult to see, darken the work area to
enhance the line.
5. Remove the protective shipping cap from the laser
devise before operation.
MATERIAL HANDLING EQUIPMENT
1. Special material handling equipment can enhanced
the performance of your machine. Contact your
DoALL sales representative for information on any
material handling needs that could increase your
productivity.
