PS-32 C PS-32 C TLC
Stroke volume cu. in (cm)
3
1.95 (32)
Bore inch (mm) 1.50 (38)
Stroke inch (mm) 1.11 (28.2)
Max. power at speed hp / rpm 1.8 / 10,000
Max. torque at speed Nm /rpm 1.6 / 7,000
Idling speed / max. engine speed with bar and chain rpm 2,800 / 12,800
Coupling speed rpm 4,100
Sound pressure level at the operator´s ear at full load according
to ANSI B 175.1
dB (A) 102
Sound pressure level at the bystanders position (50 ft/15 m
distance) according to ANSI B 175.1
dB (A) 77.5
Carburetor Type diaphragm carburator
Ignition system Type electronic
Spark plug Type NGK CMR7A-5
or spark plug Type --
Electrode gap inch (mm) .020 (0.5)
Fuel consumption at max. load per ISO 7293 kg/h 0.68
g/kWh 500
Fuel tank capacity 13.5
Chain oil tank capacity 9.5
Mixture ratio (fuel/two-stroke oil)
- when using DOLMAR synthetic oil 50 : 1
- when using other synthetic oils (oil quality must be JASO
FC or ISO-L-EGD)
50 : 1
Chain brake engages manually or in case of kickback
Sprocket pitch inch 3/8
Number of teeth Z 6
Chain type see the Extract from the spare-parts list
Pitch / gauge inch / (mm) 3/8 / 0.050 (1.3) / 3/8 / 0.043 (1.1)
Guide bar, length of a cut inch / (cm) 12, 14, 16 (30, 35, 40)
Guide-bar type see the Extract from the spare-parts list
Weight (fuel tank empty, without chain, guide bar and accessories) lbs (kg) 9.1 (4.1) 9.4 (4.2)
WARNING:
This chain saw is capable of severe kickback that coult result in serious injury to the user. Do not operate this chain
Technical data
