CAUTION: To prevent eye injury, always wear eye protec-
.
Loosen the scew (1) counter-clockwise and remove the
hood (2).
Push up the combination switch (3) (Choke position) to prevent
dirt particles from falling into the carburetor.
4) slightly in the direction of the
5).
IMPORTANT: Cover the intake opening with a clean cloth to
prevent dirt particles from getting into the carburetor.
-
washing detergent.
dry completely.
CAUTION:
Pieces of cloth or large dirt particles can destroy the
engine!
5) in the illustrated direction.
CAUTION:
-
ing it. Otherwise dirt particles on the outside surface
an engine trouble.
Note:4) will engage automatically if
Push down the combination switch (3) and press the throt-
tle (6) all the way down one time in order to deactivate the
throttle lock.
Put on the hood (2). When doing so make sure that the lower
pins (7) on both sides of the hood engage properly (when
correctly assembled, the pins should not be visible).
Tighten screw (1) clockwise.
