Dolmar PS-32 C - Cleaning the air filter compartment; fan compartment; Cleaning the cylinder fins; Replacing the suction head; Replacing;cleaning the spark arrester screen

40
16
Replacing the suction head
16) of the suction head can become clogged.
It is recommended to replace the suction head once every

carburetor.
To remove the suction head for replacement, pull it out through

form a hook.
15
15
Cleaning the air  compartment / fan com-
partment
Remove cover.
Remove the fan housing.
CAUTION: To prevent eye injury, always wear eye protec-

The entire area (15) can now be brushed clean or cleaned
with compressed air.
Cleaning the cylinder 
A bottle brush can be used to clean the cylinder 
Replacing/cleaning the spark arrester
screen
The spark arrester screen should be checked and cleaned
regulary.
Unscrew 3 screws (11) and remove the upper half of the
 (12) and then the spark arrester screen (14).
Caution: Do not use sharp or pointed objects for screen
cleaning. Damaged or misformed screen wires may result.
Reassembly the spark arrester screen as soon as the upper
 half and tighten the screws.
12
11
14
STOP
