CHANGING PRESSURE REGULATING VALVE
The numbers within brackets refer to g. U.
Disconnect the water purier from electricity.1.
Remove the top cover (two screws at rear).2.
Remove the motor assembly (3. ), see “CHANGING MO-
TOR”, point 3-6.
Disconnect all the hoses from the pressure regulating 4.
valve ().
Remove the pressure regulating valve from the brass 5.
gable by removing the two screws from the bracket
holding it ().
Make sure the bracket and screws do not fall down 6.
inside the product, also that the o-ring is removed with
the valve (4). Consider changing the o-ring as well
(separate article number).
Mount the lubricated o-ring on the new pressure regu-7.
lating valve and mount the bracket on the valve.
Press the valve assembly gently into position in the 8.
brass gable. Be careful, sharp edges of the brass gable
might cut the o-ring.
Secure the valve in place with the two screws.9.
Reconnect all the hoses to the pressure regulating valve. 10.
Reinstall the motor assembly, see “11. CHANGING MO-
TOR”, point 11-17.
Connect to electricity and the product will start to ush.12.
Check for leakages.13.
Put back the top cover.14.
SERVICE
in alignment with the valve housing.
