-When the machine has been modified to work with a different type of gas to that specified, the corresponding
new name plate and yellow label will be having to put on it, which is inside the plastic bag of the new injectors.
If a smell of gas is detected:
• Close the main gas supply and ventilate the room.
• Do not turn only any lights or connect any electrical device.
• Do not use the telephone in the room.
3.7. Steam connection (Only steam models)
The installation of the dryer with steam heating (powered at high or low steam pressure), must meet
current standard regulations.
The dryers normally work at pressures ranging from 600 KPa to 900 KPa. Check the pressure on the
CE plate and connect the correct operating pressure.
The location of the steam input is shown in the figures given in section 3.9.
The steam installation must be made such that the steam reaches the machine in optimum conditions.
Without condensation and free of impurities.
The manual shut-off valve should be installed at the input to the machine for maintenance purposes. A
filter should also be fitted.
Some instructions regarding the steam installation:
• The main pipe must have a negative slope of 1%.
• The connection between the main pipe and the
bypass should be in the upper part of the
principal line.
• The bypass pipe to the machine shall have a
negative slope and it must not be possible for
condensation to build up in any of the syphons.
