4.2.1. Information displayed with the indicator lights.
The indicator lights (LED) show the machine modes, the temperature settings, and the time remaining,
in the following way (in the previous picture these are points 2, 4 and 6):
Indicator
Mode indicator
Machine status
Remarks
2
Start/Stop
Off
Machine stopped /
paused
If there is time available, a
drying cycle can be started.
Green
Machine operating
A drying cycle is running.
Red flashing
Alarm or warning
Machine in Alarm or Warning
mode. See Alarms and
Warnings section for further
information.
6
Temperature
LED High
temperature lit
High temperature
selected
-
LED Medium
temperature lit
Medium temperature
selected
-
LED Low
temperature lit
Low temperature
