Donaldson Company, Inc.
28
55-Gallon Drum Pack
The drum pack is designed to fit a customer-
supplied, standard 55-gallon drum and provides easy
access for dust removal and disposal. A flexible hose
connects the drum cover and slide gate, or drum
cover and adapter. Placing a pallet under the drum
allows heavier product to be moved quickly using a
forklift or pallet jack. If a pallet is used, the length of
flexible hose may need to be shortened.
With Slide Gate
1. Place the 1/8-in gasket spacer between the
hopper flange and slide gate as shown.
2. Attach the drum pack and slide gate to the
hopper flange using 3/8-16 bolts, washers, and
hex nuts.
3. Attach the drum cover to the 55-gallon drum.
4. Use latches to secure the cover to the drum, if
equipped.
5. Connect the flexible hose between the drum
cover and slide gate. Secure with hose clamps.
Without Slide Gate
1. Place the 1/4-in diameter rope-type sealant
between the hopper flange and the adapter as
shown.
2. Attach the adapter to the hopper flange using
3/8-16 bolts, washers, and hex nuts.
3. Attach the drum cover to the 55-gallon drum.
4. Use latches to secure the cover to the drum, if
equipped.
5. Connect the flexible hose between the drum
cover and the adapter. Secure with hose clamps.
