Downflo II, Model DFT 2-8 through 4-128
5
All Units ( per IBC 2003 Specifications):
Wind ........................................ 90 MPH Exposure C
Seismic Spectral Acceleration, S
s
............................................
1.5
Seismic Spectral Acceleration, S
1
...........................................
0.6
Importance Factor, 1............................................ 1.0
Ground Snow Load ............................... Pg = 40 PSF
Compressed air, psi ........................................90-100
Housing rating, "wg ..........................................+-20
Power, valves and controls .... 120-Volt AC, 50/60 Hz
Rating and Specification Information
*VSRX
(*81SHIP
*VSRX
(*81SHIP
*VSRX
(*81SHIP
(*8*VSRX
[MHIQSHIPW
(*8*VSRX
[MHIQSHIPW
7MHI:MI[
%PP1SHIPW
