Donaldson Torit DFT 2-8 - Electrical Wiring and Rigging; Electrical Wiring; Rigging Instructions; Hoisting Information

Donaldson Company, Inc.
8
CAUTION!
 Failure to lift the collector correctly
can result in severe personal injury or
property damage.
 Use appropriate lifting equipment and
adopt all safety precautions needed for
moving and handling the equipment.
 A crane or forklift is recommended for
unloading, assembly, and installation
of the collector.
 Location must be clear of all
obstructions, such as utility lines or
roof overhang.
Electrical Wiring
Rigging Instructions
Suggested Tools & Equipment
Clevis Pins and Clamps Lifting Slings
Crane or Forklift Pipe Sealant
Drift Pins Pipe Wrenches
Drill and Drill Bits Screwdrivers
End Wrenches Socket Wrenches
Large Crescent Wrench Spreader Bars
Hoisting Information
1. Use all lifting points provided.
2. Use clevis connectors, not hooks, on lifting
slings.
3. Use spreader bars to prevent damage to units
casing.
4. Check the Specification Control drawing for
weight and dimensions of the unit,
subassemblies, and components to ensure
adequate crane capacity.
5. Allow only qualified crane operators to lift the
equipment.
6. Refer to applicable OSHA regulations and local
codes when using cranes, forklifts, and other
lifting equipment.
7. Lift unit and accessories separately, and
assemble after unit is in place.
8. Use drift pins to align holes in section flanges
during assembly.
CAUTION!
 Electrical installation must be
performed by a qualified electrician
and comply with all applicable
national and local codes.
 Lock out electrical power sources
before performing service or
maintenance work.
 Do not install in classified hazardous
atmospheres without an enclosure
rated for the application.
1. All electrical wiring and connections, including
electrical grounding, should be made in
accordance with the National Electric Code,
NFPA No. 70-latest edition.
2. Check local ordinances for additional
requirements that apply.
3. The appropriate wiring schematic and electrical
rating must be used. See units rating plate for
required voltage.
4. If the unit is not furnished with a factory-
mounted disconnect, an electric disconnect
switch having adequate amp capacity shall be
installed in accordance with Part IX, Article 430
of the National Electric Code, NFPA No. 70-
latest edition. Check units rating plate for
voltage and amperage ratings.
5. Refer to the wiring diagram for the number of
wires required for main power wiring and
remote wiring.
