Solar sensor
4.3-29
Solar sensor
Removal and refitting of solar sensor
1- Protection
Place protective pads at following positions:
• Front fender;
• Front bumper;
• Driver’s seat;
• Carpet (on driver's side);
• Steering wheel;
• Parking brake lever;
• Shift lever.
2 - Removal
• Pry open the front solar sensor (1) on the
right side of the instrument panel with a
slotted screwdriver.
• Press the locking clip of the connector and
disconnect the solar sensor connector (1).
• Remove the solar sensor (2).
• Pull the solar sensor outward during
disconnecting the solar sensor connector (1).
In order to avoid the wire harness being
retracted inside the instrument panel to affect
the installation after the connector is
disconnected.
To Next Page
