Main unit of MP5
4.3-37
Main unit of MP 5
Configuration writing after MP5 main unit
replacement
1- Protection
Place protective pads at following positions:
Front fender;
Front bumper;
Driver’s seat;
Carpet (on driver's side);
Steering wheel;
Parking brake lever;
Shift lever.
2- Configuration writing
CAUTION
Configuration writing is necessary after the
MP5 A/V main unit is replaced.
Connect the special scan tool to diagnostic
interface.
Set the ignition switch or start-stop button to
ON.
Enter the “Diagnostic Function Interface” of
the scan tool to select the E70 model.
Select the “WindLink 2.0 plus” menu to
proceed to the next step.
Select the “A/V system MP5 menu to
proceed to the next step.
Click on the “Configuration Information
Update” menu in the “A/V system MP5
menu to proceed to the next step.
Select 300 E1 Private Car” in the
“Configuration Information Update” menu
and confirm.
Configuration writing of model with MP5 is
completed with the “Model Configuration
Number Writing Succeed” displayed.
After the configuration is completed, read
the A/V system MP5 DTC and clear it. After
clearing, read again and confirm that the
DTC is completely cleared.
300 E1 private car
System identification
Read trouble code
Clear trouble code
Parameter
measurement
After-sales information
writing
Configuration
information update
