T-BOX
4.3-39
T-BOX
Configuration writing after T-BOX
replacement
1- Protection
Place protective pads at following positions:
Front fender;
Front bumper;
Driver’s seat;
Carpet (on driver's side);
Steering wheel;
Parking brake lever;
Shift lever.
2- Configuration writing
CAUTION
The T-BOX is only available for the 300 E1
private car model, and configuration writing
is necessary after the part is replaced.
Connect the special scan tool to diagnostic
interface.
Set the ignition switch or start-stop button to
ON.
Enter the diagnostic function interface of the
scan tool.
Select the “Remote Module Activation”
menu to proceed to the next step.
Click on the “Configuration Information
Update” menu in the “Remote Module
Activation” menu to proceed to the next
step.
Select 300 E1 Private Car” in the
“Configuration Information Update” menu
and confirm.
T-BOX configuration writing is completed
with the “Model Configuration Number
Writing Succeed” displayed.
After the configuration is completed, read
the T-BOX DTC and clear it. After clearing,
read again and confirm that the DTC is
completely cleared.
System identification
Read trouble code
Clear trouble code
Parameter
measurement
After-sales information
writing
Configuration
information update
300 E1 private car
