Tire pressure monitoring system
4.3-10
Tire pressure mo nitoring system
Removal and refitting of tire pressure
sensor
1 - Removal
• Turn off the ignition switch, and disconnect
the battery negative cable.
• Remove the wheels. (Refer to "Removal and
Refitting of Wheels" in this section.)
• Remove the tire with a tire changer (1).
(Refer to "Removal and Refitting of Tires” in
this section.)
• When pressing the bead away from the edge
of the rim, always keep the tire changer
presser 90° above the valve, otherwise the
sensor will be easily damaged.
• Remove the fixing nuts (1) of the tire
pressure sensor with a 11mm socket
wrench.
• Remove the tire pressure sensor with valve
assembly (2).
To Next Page
