Dorma 9600 Series - Bottom Strike Preparation

L
C
L
C
L
C
For surface strike
drill (2) 5/16" dia.
holes, x 1" in depth
for lead anchors.
Secure with (2)
#12 x 1" F.H.P.T.S.
1"
2"
2 3/4"
1"
#439 Strike
1 1/2"
3/8"
#340 Strike
#431 Strike
1 3/8"
5/16"
12
Note: 1 5/16" min. to
1 5/8" max. square cut
out for recessed strike
1" in depth.
1 1/2"
Drill 13/16" Dia.
1" in depth.
Finished floor
Of latch
1" Inside face
of door
Of strike
Finished floor
1/4"-20 x 1"
R.H.P.M.S.
Steel anchors
Optional slide bolt No. 340 strike installation
Optional pullman latch No. 431 strike installation
Inside face of door.
Of strike
Note: Drill
5/8" dia. hole
1/2" deep min.
1/4" Ref.
1/4" Ref.
7/8"
BOTTOM STRIKE PREPARATION
Top of threshold
3/16" Ref.
Top of threshold
3/16" Ref.
Top of threshold
3/16" Ref.
