(DEVICE SIDE ONLY)
3/8" DIA. HOLE
INSIDE FACE
OF DOOR
HORIZONTAL REF. LINE
DIA. (2) PLACES
1/4"
7/32" DIA. HOLE
13/16"
VERTICAL REF. LINE
(CENTERLINE OF CHASSIS)
1 3/16" DIA. HOLE
(TRIM SIDE ONLY)
OF DOOR
OUTSIDE FACE
OF
STOP
EDGE
(SEE STEP 2)
OR
MULLION
(DEVICE SIDE) (TRIM SIDE)
1/4"
NOTE: If using 80CK
cyinder adapter kit with
trim; hole diameter re-
quired is 1 3/8".
VERTICAL REF. LINE
(CENTERLINE OF CHASSIS)
(SEE STEP 2)
4
9600/F9600
Concealed Vertical Rod Exit Device
RHR Shown
LHR Opposite
Required for "03" & "04" function on device
with cylinder only and no trim.
(NOT TO SCALE)
ADDITIONAL DOOR PREP REQUIREMENTS
IMPORTANT NOTE:
NOTE: "04" function not
available on fire rate device.
"Fire rated devices can not
be dogged."
Hole dimensions may
vary, when using cylinder
by other manufacturer's
use backplate supplied
with cylinder as drilling
template.
