ED400 In Floor
Controller Manual
8
DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211 DL3128-010
Lake Bluff, IL 60044 Fax: 877-423-7999 10/1/2007
E-mail: automatics@dorma-usa.com Subject to change without notice
This table lists the basic settings.
Position of Function of
"Selector" knob "Dial" knob Display Units
Type Opener Type “L.E.”: Low Energy, “P.A.”: Power
Assist; “Ful”: full power
Mount Select door mount Use “OCN” Setting
Open Speed increment/decrement Opening speed to Back-Check °/s
Back-Check increment/decrement Back-Check angle °
Back-Speed increment/decrement Speed reaching Back-Check °/s
Back-Stop increment/decrement Back-Stop angle °
Close delay increment/decrement (a.k.a.: "Hold Open Time") s
Time at Back-Stop
Colse speed increment/decrement Max closing speed to Latch-Check °/s
Latch-Check increment/decrement Latch-Check able °
Latch-speed increment/decrement Max closing speed to Latch-Stop °/s
Triggers are enabled while the Selector knob is in the Run or Monitor value position, and
disabled otherwise.
For more information on these items see the Menu Reference section.
• Test full operation. When you’re happy with the cycle, stop the Learn Cycle.
o Set the Program Switch in the "Off"position. The door will stop cycling.
o Turn the "Selector" knob to the "Run" position. The display shows the
present State of the opener. If there's an exception, it will show a code for it.
• Test the opener's operation with the sensors
Advanced adjustments
While the basic settings are typically sufficient to set-up the opener, additional ones are abailable
through the Misc Menus, such as:
• Push-and-go
• Power Hold
• Obstacle detection sensitivity
For a complete list of settings see the Menu Reference / Misc Menus section.
Position of Function of
"Selector" knob "Dial" knob Display Units
Misc-select Select a miscellaneous Code for the selected setting -
setting to be adjusted
Misc-adjust Adjust the selected Value of the selected setting -
miscellaneous setting
These settings are selected and adjusted indirectly, in two steps, with the Selector and Dial
knobs.
o Turn the "Selector” knob to the “Misc Select” position.
o Turn the "Dial" knob until the desired setting is shown in the display.
o Turn the "Selector” knob to the “Misc Adjust” position. The display will
show the present value of that setting
o Turn the "Dial" knob to adjust the value of that setting.
RUN
