Assembly Instruction Replacing battery A01
060675 45532/17224 - 07/2023 ED UPS 13
8 Replacing battery A01
WARNING
Risk of injury due to technical errors
Technical errors can lead to uncontrolled movement of the unit. In the case of
electrical units, this can also lead to electric shock.
• De-energize the unit prior to performing repairs.
NOTICE
Property damages due to incorrect spare parts
dormakaba uses the best possible components for each application. If one of
these components needs to be replaced, proceed as follows:
• Use original replacement parts from dormakaba.
• If spare parts are used that are not original spare parts, their operational ca-
pability must be coordinated with dormakaba and approved in writing.
ð In all other cases, dormakaba's warranty shall be deemed null
and void
Procedure
1. Switch off the ED100/250 at the power switch.
2. Disassemble the ED 100/250 casing cover.
3. Disconnect the ribbon cable.
4. Remove the plug for A01 battery on the ED-AMP board.
5. Remove the cover of the battery casing.
6. Pull the cables of the defective A01 battery through the cover of the casing
and insert the new A01 battery.
7. Insert the A01 battery into the housing and guide the cables through the
cover.
8. Close the cover of the battery casing.
9. Connect the plug for A01 battery to the ED-AMP board.
DANGER
Danger of death due to door leaves
The ED UPS supplies the ED100/250 with voltage regardless of the power switch
setting. As a result, the ED100/250 can no longer be switched off.
• Prior to taking the next working step, check that there are no people or ob-
jects in the range of motion of the door leaves.
• Secure the range of motion of the door leaves.
10. Plug in the ED ribbon cable.
11. Mount the casing cover of the ED 100/250.
12. Switch on the ED 100/250 at the power switch.
