Dormakaba ED - Product Description; Sales and Spare Parts; Technical Data

Assembly Instruction Product description
060675 45532/17224 - 07/2023 ED UPS 5
3 Product description
3.1 Sales and spare parts
Article number Components
29263020 A01 battery
29263021 ED UPS mounting set single-leaf
Cladding: silver
29263022 ED UPS mounting set single-leaf
Cladding: white
29263023 ED UPS mounting set double-leaf
A protective cover is not included with this item.
29280057 ED charging electronics for UPS active door leaf
29280062 ED charging electronics for UPS passive door leaf
The core components of the ED UPS are an ED-AMP board, a connection cable, the
battery casing and an ED RBI board for double-leaf doors.
The battery is not included. This must be ordered separately.
3.2 Technical data
Voltage 28.8 V
Battery capacity 3.2Ah
Operating temperature
Charging process
Discharge process
0°C to +50°C
-15°C to +50°C
Storage temperature -20°C to +25°C
Weight Approx. 2.8 kg
Battery type designation BatteryA01,IFR18650E1-1600-9S2P
• The battery pack only reaches its full capacity after around 6 hours of
charging time.
• The battery pack must be fully charged to ensure emergency operation.
For a single-leaf door with a door weight of 100 kg and a door speed of 25°/
second, the A01 battery provides about 600 door openings.
For a double-leaf door with a door weight of 100 kg and a door speed of 25°/
second, the A01 battery provides approx. 300 door openings.
