Information about this document Assembly Instruction
2 ED UPS 060675 45532/17224 - 07/2023
1 Information about this document
1.1 Contents and purpose
This document describes the mounting, connection and commissioning of the ED
UPS.
1.2 Target group
The product may only be mounted and commissioned by a qualified electrician.
1.3 Other applicable documents
• ED 100, ED 250 operation manual
• Mounting and commissioning ED 100, ED 250
1.4 Abbreviations and terms
ED100/250 Electromechanical swing door operators for the
automatic opening and closing of swing doors.
UPS Uninterrupted power supply
ED-AMP Battery management board for the ED100/250
during single-leaf operation, as well as for the
primary ED100/250 during double-leaf opera-
tion.
ED-RBI A board which serves as an interface for
rechargeable batteries (Rechargeable Battery
Interface) for the secondary ED100/250 during
double-leaf operation.
1.5 Symbols used
1.5.1 Hazard category
DANGER
Describes an imminent danger resulting in serious injury or death.
WARNING
Describes a potentially dangerous situation that may result in serious injury or
death.
NOTICE
Means a potentially harmful situation where the product or something in its
environment could be damaged or result in a malfunction.
