dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Chapter 11
. Set door type parameter dL
Step 
Press
Scroll to dL parameter.
Step 
Press
Displays "" , factory setting.
Step 
Press
"" starts flashing.
Step 
Press
Scroll to "".
Step 
Press
Scroll to "".
Step 
Press
Saves value.
Display stops flashing.
Step 
Press
Returns to door type parameter.
Step 
Press
Exits program mode.
.. Set parameter dL, door type = .
Door type
Parameter
value
Parameter description
* Single door

Pair doors, with astragal.
Active door operator, door opens first.

Pair doors, with astragal.
Inactive door operator.

Pair doors, without astragal.
Active door operator. Both doors open
simultaneously.

Pair doors, without astragal.
Inactive door operator. Both doors open
simultaneously.
Table .. Door type parameter dL values.
*dL factory setting = .
.. Set dL door type parameter value.
NOTICE
. Set dL =  (single door =).
• "" is dL factory setting.
• For system to recognize dL= , steps in
Para. .. must be followed.
dL must be set to "" for single door
commissioning.
Fig. 11.7.1 4 button keypad,
2 digit display
1 4 button keypad
2 2 digit display
> 3s Reset
< 3s Quit
LEARN
< 3s
> 3s
Fact-Setup
PRG
> 3s
> 8s
1
2
TIPS AND RECOMMENDATIONS
If display shows
after basic
parameters have been set:
• Press
for  seconds.
•
will be displayed.
